GENESIS PROBE

통상적으로 사용되는 제품들의 경도를 한층 업그레이드하여 내마모에 대한 성능 향상을 기대 할 수 있습니다.

sortation	Product Specifications
Spring Force	Initial Force	7.6gf
	Recommended Stroke	35.0gf @ 0.55mm
	Full Stroke	42.5gf @ 0.70mm
MaTerial Spec.	Barrel	Phosphor Bronze Tube (Au Plated)
	Top Plunger	Hardened BeCu (G3)
	Bottom Plunger	Hardened Steel (Au Plated)
	Spring	Music Wire (Au Plated)
Mecahnical Spec.	Pointing Accuracy	±0.05mm
	Operating Temperature	-45 to +125˚C
	Spring Life Expectancy	250k Cycle
Electrical Spec.	DC Resistance (Avg.)	Less Than 100mΩ
	Current Rating	1.0 A Continuous (Reference)
	Band Width	TBD (To Be Determined)
	Self Inductance
	Capacitance
